TP 370,750,755 - ECA004 Mouse button failures

15.727 bytes

Service Hints & Tips

Document ID: MCGN-3LUN4N

This document is provided to IBM and our Business Partners to help sell and/or service IBM products. It is not to be distributed beyond that audience or used for any other purpose.

TP 370,750,755 - ECA004 Mouse button failures

Applicable to: World-Wide

Record number:

H16779

Service code:

33

Device

D/T9545

Parts source:

LOC

ECA number

ECA004

Publishing flag:

H

EC number:

EC999999

Hit count

UHC00163

Mandatory:

N

Success count:

USC0000

Automatic shipment:

N

Publication code:

PC40

Availability date:

97/08

Date created:

O97/07/18

Plant of control:

23

Date last altered:

A97/09/23

Tip key:

Owning B.U.:

USA

PURPOSE:
Replace the ThinkPad keyboard to correct a failing mouse button condition.

Features :

Type, Model, Stage

With B/M

Machines Affected
and/or
Feature/Device

B/M to be
Installed

Service Hours

System Hours

9545

B/M9999999

All 750, 755, and 370

B/M9999999

00.4

00.2

PHYSICAL CHECK:
9545 ThinkPads systems listed in the features section must have all of the following to qualify for this ECA:

1. A solid or intermittently failing mouse button.

2. A keyboard with a label "Manufactured for IBM by Lexmark" on the keyboard base.

The new keyboard will have the following label on it. These keyboards are not eligible for this ECA.

EXAMPLE:

PREREQUISITES: NONE

COMPANION:

CONCURRENT: NONE

DETAIL:
Some 9545 mouse buttons that receive a high amount of use may exhibit intermittent or solid failures during use.

The FEATURES section identifies the 9545 models that can be affected and are eligible for this ECA.

A new keyboard with a more robust button is now in FRU stock. The FRU part number has not changed. The label shown in the Physical Check area identifies this new level keyboard.

This ECA covers all keyboard languages.

NOTES:
This ECA will expire Spetember 23, 1999. Order FRUs locally and record all time using Service Code 33, ECA004, other office 990.

Search Keywords

Hint Category

ECA, Input Devices

Date Created

12-09-97

Last Updated

30-09-98

Revision Date

29-09-99

Brand

IBM ThinkPad

Product Family

ThinkPad 370, ThinkPad 750, ThinkPad 755C/CS

Machine Type

9545

Model

TypeModel

Retain Tip (if applicable)

H16779, ECA004
