Service Hints & Tips |
Document ID: GSMH-3FCDCB |
IBM PC/IBM IntelliStation - CD-ROM, PD/CD-ROM drive jumper settings
Applicable to: World-Wide
CD-ROM, PD/CD-ROM drive jumper settings:
CD-ROM and PD/CD-ROM drives use jumpers or tabs to set the drives as primary (master) or secondary (slave). Refer to the drive connector labels or the figures below for the drive settings.
|
Search Keywords |
| |
|
Hint Category |
Hardware Maintenance Information | |
|
Date Created |
20-03-97 | |
|
Last Updated |
18-05-99 | |
|
Revision Date |
26-05-2000 | |
|
Brand |
IBM IntelliStation, IBM PC | |
|
Product Family |
M Pro, Z Pro, PC 300GL, PC 750, PC 730, PC 365, PC 360, PC 350, PC 340, PC 330, PC 300PL, PC 300XL | |
|
Machine Type |
6888, 6889, 6898, 6899, 6272, 6282, 6561, 6591, 6562, 6592, 6862, 6892, 6588, 6571, 6573, 6575, 6576, 6577, 6560, 6581, 6583, 6585, 6586, 6587, 6598, 6589, 6875, 6876, 6877, 6885, 6886, 6887, 6284, 6897 | |
|
Model |
All | |
|
